Description

Operating temperature range	Max.Operating temperature.,Top,max:+85℃ Upper category temperature:+70℃ Lower category temperature:-40℃
Capacitance range	50μF~4000μF
Rated voltage	450V.DC~4000V.DC
Cap.tol	±5%（J）；±10%（K）
Withstand voltage	Vt-t 1.5UN DC/60s Vt-c 1000+2×UN/√2(V.AC)60S(min 3000V.AC)
Over voltage	1.1Un(30% of on-load-dur.) 1.15Un(30min/day) 1.2Un(5min/day) 1.3Un(1min/day) 1.5Un(100ms every time,1000 times during the lifetime)
Dissipation factor	tgδ≤0.003 , f=100Hz tgδ0≤0.0002
Insulation resistance	Rs×C≥10000s（at20℃ 100V.DC 60s）
Withstand strike current	See the specification sheet
Irms	See the specification sheet
Flame retardation	UL94V-0
Maximum altitude	3500m Derating should be considered when the altitude is between 3500m -5500m. (For each increase of 1000m, voltage and current will be reduced by 10%)
Life expectancy	100000h（UN;θhotspot≤70℃）
Reference standard	IEC61071; GB/T17702

Long LifeCRE Capacitors Feature Long Life, Self-Healing Capabilities, And Rugged Construction, Making Them Suitable For Industrial And Electronic Equipment With High Reliability Requirements.
Self-HealingThe Self-Healing Properties Ensure That Small Defects Are Automatically Repaired For Continued Stable Operation.
Aluminum HousingThe Aluminum Housing And Resin Filling Provide Better Moisture Resistance, Shock Resistance, And Heat Dissipation, Allowing Them To Perform Well In Harsh Environments.
